Double eccentric butterfly valve
Double eccentric butterfly valve

Item specifics

Keywords
butterfly valve
Valve type
BUTTERFLY VALVE
Function code
expansion
Product name
Double eccentric butterfly valve

Review

Description

Product Description
Purpose
The butterfly valve integrates advantages of both concentric rubber lined butterfly valve and eccentric soft seal butterfly valve.It is designed as a device to shut-off or regulate the working medium flow and installed in indusigned as a device with corrosive medium,such as weak acid.Alkali and etc.

Features and Benefits.
1.Double eccentric structure provides a very low friction torque,rapid open-close.excellent operation.light weight and labor saving.
2.Body and disc vulcanised with hard rubber are cornpletely isolated from working medium.
3.Integrated advantages of common concentric rubber lined butterfly valve and double eccentric soft seat butterfly valve.
4.Zero leakage sealing in bi-directional.
5.Special for corrosive working medium such as water and provides long life service and significant cost saving.
Product Specification
Detail Images
expansion joint
Related Products
Related products
Related products
Company Information
   Our company produces all kinds of industrial valve, such as valve, tianjin valve, tanggu valve, butterfly valve, tianjin butterfly valve, tanggu butterfly valve, wafer butterfly valve, flange butterfly valve, welded butterfly valve, soft sealing butterfly valve, hard sealing butterfly valve, gate valve, shut-off valve, ball valve, check valve, decompression valve, hydraulic control valve etc.

  Tianjin Aiwo Valve Co., Ltd is a professional manufacturer of valves and its fittings for over 20 years, providing designing, producing, managing and after-sale service. Our products can be divided to 8 series: butterfly valve, ball valve, gate valve, check valve, stop cock valve, regulating valve, hydraulic control valve and decompression valve. The DN sizes ranges from 15mm to 3800mm, and the pressure ranges from 0.1MPa to 32MPa. Moreover, our products can be widely used in waterworks, sewage treatment plant, power plant, chemical plant, gasworks, heating company, oil fields, oil refineries, and high-rise buildings.

   We will continuously develop and innovate to keep pace with the development in building construction, water conservancy, energy and electric power, petrochemical field. And in order to grow up to be China’s largest valve research and develop base and rank among the world first class, we are determined to develop high-tech, new design, complicated and special products. At the same time, “never the best, but more better” is always our company’s goal.

  Welcome elites to join our sales network, as well as set up offices in name of our company. Any interest, please call us.
